SKYLAB Bluetooth gateway Receiver for Indoor Positioning System

SKYLAB Bluetooth Beacon Receiver for Indoor Positioning System Product Description

Bluetooth Beacon Receiver for Indoor Positioning System
Dimension	Diameter: 110mm; Height: 35mm
Power Supply	DC4.5-5.5V,POE Switch up to 57V
Average Current	200mA@5V
Work Temperature	-20℃~70℃
Physical Interface	WAN Port and Power Supply Port



Wifi Parameters
WiFi Protocol	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Data Rates	IEEE 802.11 b Standard Mode: 1,2,5.5,11Mbps
	IEEE 802.11g Standard Mode: 6,9,12,18,24,36,48,54Mbps
	IEEE 802.11n : 72Mbps @ HT20                          150Mbps @ HT40
Receiver Sensitivity	HT40 MCS7 : -67dBm@10% PER(MCS7)
	HT20 MCS7 : -73dBm@10% PER(MCS7)
	54M: -76dBm@10% PER
	11M: -91dBm@ 8% PER
Transmit Power	IEEE 802.11n: 15dBm @HT40 MCS7                       15dBm@HT20 MCS7
	IEEE 802.11g: 16dBm
	IEEE 802.11b: 18dBm
Wireless Security	WPA/WPA2, WEP, TKIP, and AES
Work Mode	Bridge,Gateway,AP Client



Bluetooth Parameters
Bluetooth	Bluetooth ® 4.2
Data Rates	1Mbps
Wireless Security	AES HW Encryption
Coverage Area	100m
Transmit Power	0~+20dBm

   TD05A is a Bluetooth Gateway with POE or DC power supply. It can be used in various scenarios flexibly. For example, the remote control BLE device, receives the data sent by the BLE device and sends it to servers. The WiFi data rate of TD05A can be up to 100Mbps and BLE data rate can be up to 1Mbps. TD05A also supports the POE switch power supply and 5.0V adapter power supply.     Hot Sale Product Company Information SKYLAB M&C Technology Co.,Ltd, located in Shenzhen, China. specialized in WiFi, Bluetooth,GNSS and other wireless products research and development. Own a professional team which have rich experiences of GNSS/WiFi/Bluetooth/UWB/NB-IoT/GPRS hardware&software development and RF tech. Aiming to supply high-quality, high-performance wireless modules and relevant application solutions to domestic and overseas customers who need OEM/ODM and system integrators.Committed to create long-term market value and potential increase for customers. Test & Certificate   SKYLAB Advantage Project & Developmen   FAQ   Contact Us
