SKYLAB hot sale low power BLE 5.0 bluetooth mesh Nordic nRF52840 transceiver bluetooth module for Beacon

SKYLAB hot sale low power BLE 5.0 bluetooth mesh Nordic nRF52840 transceiver bluetooth module for Beacon  Product Description

Hardware Features
Model	SKB501
ANTenna Type	PCB Antenna or IPEX connector
Chipset Solution	nRF52840
Voltage	1.7V~3.6V
Dimension(L×W×H)	17.4×13.7×1.9 mm
Wireless Features
Wireless Standards	Bluetooth 5/ANT
Frequency Range	2400MHz---2483.5MHz
Data Rates	1Mbps(Bluetooth 5)
Modulation Technique	GFSK Modulation(Bluetooth 5)
Wireless Security	AES HW Encryption
Transmit Power	Tx Power -20 to +8 dBm in 4 dB Steps(Bluetooth ® 5.0)
Work Mode	Central/Peripheral(Bluetooth ® 5.0)
Others
Certification	RoHS
Environment	Operating Temperature: -40℃~85℃
	Storage Temperature: -40℃~125℃
	Operating Humidity: 10%~90% Non-condensing
	Storage Humidity: 5%~90% Non-condensing

  Ready for Bluetooth 5 and high grade IoT security  The SKB501 is an advanced, highly flexible single chip solution for today’s increasingly demanding ULP wireless applications for connected devices on our person, connected living environments and the IoT at large. It is designed ready for the major feature advancements of Bluetooth® 5 and takes advantage of Bluetooth 5’s increased performance capabilities which include long range and high throughput modes. Inherent industry-grade security is essential in today’s applications.  Bluetooth 5 – Bluetooth low energy further and faster  The nRF52840 is ready to take advantage of the considerable performance improvements for Bluetooth low energy with the arrival of the Bluetooth 5 specification. Of greatest importance is the support for longer range (up to x4 compared to Bluetooth 5.0) and doubling of on-air data-rate, up to 2Mbs from 1Mbs in Bluetooth 5.0 Wide protocol support with addition of 802.15.4  The 802.15.4 PHY and MAC layers are supported natively on the nRF52840. This allows nRF52840 to be used in a wide range of home and industrial sensor network applications as it supports two of the most popular wireless sensor standards in use today, Bluetooth low energy and 802.15.4 derivatives. This adds to the already existing radio support for Bluetooth low energy, ANT/ANT+ and 2.4GHz for proprietary.   Features Bluetooth 5 ready multi-protocol radio    Bluetooth 5 datarate support: 2Mbs, 1Mbs, 500Kbs, 125Kbs Support ANT Protocol 32-bit ARM Cortex-M4F @ 64MHz Up to 111 dB link budget for Bluetooth long range mode NFC-A on-chip Programmable output power from +8dBm to -20dBm -96dBm Sensitivity for Bluetooth low energy RSSI Wide supply voltage range +5.5v to 1.7v Full selection of interfaces SPI/UART/PWM Programmable Peripheral Interface - PPI High speed SPI interface 32MHz EasyDMA for all digital interfaces 12bit/200K SPS ADC 128 bit AES/ECB/CCM/AAR co-processor 20 General Purpose I/O pins SPI Master/Slave Two-wire Master (I2C compatible) UART (CTS/RTS) RoHS compliance (Lead-free) FCC,CE compliance
